Automatic temperature control and high humidity thawing equipment for meat processing

US$20,000
1-1 set
US$19,900
≥2 sets
Model
Power (W)

Customization options

  • logo/graphics customization process(Minimum order: 50 sets)
Get a quote
Ask an expert
Product features
  • Internal components: air distribution bracket, water tray, air guide plate, air distribution plate, fan support panel, and air guide plate are all made of 304 stainless steel.
  • Air circulation: Equipped with a special axial flow fan for cold storage. The shell and bracket are made of 304 stainless steel. The motor adopts a moisture-proof and low-temperature resistant motor with cast aluminum blades.
  • Evaporation system: It adopts high-efficiency copper tubes and aluminum fins with surface oxidation treatment, and is protected by a stainless steel shell.
  • Heat Source: Compatible with water steam or electric steam generators. Heat is conducted to the chamber through a dedicated piping system.
  • Atomization process: water vapor is atomized through a double-pipe pressure reduction process. For the electrical system, the water tank is heated and circulated through a high-pressure water pump to achieve atomization.
  • Auxiliary humidification features a pressurized water mist system that works with air circulation to disperse moisture evenly throughout the unit.
  • Core features: high humidity thawing equipment, working principle, internal structure and material specifications, humidification and heating system.
  • Automatic temperature control and high humidity thawing equipment is designed to provide a fast and safe thawing environment for frozen meat products. By utilizing low-temperature, high-humidity circulating air, the system ensures that products transition from frozen to processed states with minimal moisture loss and maximum hygiene.
  • The equipment operates by circulating low-temperature, high-humidity air around the frozen product. Multiple fan blades within the airbox create even airflow, ensuring consistent heat transfer across all surfaces.
  • By maintaining a high humidity of around 90%, air becomes a more efficient heat transfer medium. The entire process is managed by a PLC microcomputer, which automatically adjusts temperature, humidity and duration in stages. This precise control maintains the thawing environment at around 10 degrees Celsius, a critical threshold that inhibits bacterial growth while preventing structural damage associated with rapid heating.
Properties

Core industry attributes

Application scopecold room
Warranty1 year
core selling pointHigh productivity
core componentsMotor
Mechanical test reportAvailable
Factory video inspectionAvailable

Important attributes

Application scope
cold room
Mechanical test report
Available
core selling point
High productivity
core components
Motor
Warranty
1 year
Factory video inspection
Available
Origin
Shandong, China
weight
100
brand name
One Stop Engineering
Voltage
380 volts
Dimensions (length*width*height)
2900×2100×2400

Packaging and shipping

sales unit
single item
Individual package size
2900X2100X2400 cm
Gross weight of a single product
4000.0 kg
