Evaporative condenser cooling equipment for industrial refrigeration systems and cold chain applications
US$5,500
1-1 set
US$5,300
≥2 sets
Model
Air volume
cooling capacity
Product features
Properties
pictures
Product features
- Key components: The system includes high-performance fans, inlet and outlet pipes, spray pumps, heat exchange coils, sinks, demisters and air ducts. All parts in contact with the circulating medium are made of high-quality 304 or 316 stainless steel, ensuring excellent corrosion resistance and hygiene. The shell is made of magnesium aluminum zinc alloy or 304 stainless steel for enhanced durability.
- Working principle: Fresh air enters from the bottom of the unit and moves upward in countercurrent to the sprayed water. As the water evaporates, it absorbs heat from the refrigerant circulating within the coil, effectively cooling the refrigerant. An axial flow fan then exhausts the moist warm air while collecting the remaining water, filtering it through a demister and recycling it. This design maximizes heat exchange efficiency while minimizing water consumption and system footprint.
- Compact structure: counter-flow design, air intake from all sides, uniform air flow, and higher space utilization. The tower's compact internal layout saves valuable installation space without compromising performance.
- Excellent heat exchange efficiency: With a larger height difference between the air inlet and air outlet, the unit can avoid short circuits and ensure low inlet air humidity, thereby increasing cooling capacity. Optimized fan layout promotes even air distribution, minimizing dead spots and maximizing heat dissipation.
- Easy to install and transport: The condenser can be pre-assembled with ancillary components into a single modular unit, simplifying transport, installation and future maintenance. This makes it ideal for projects that require rapid deployment.
Properties
Core industry attributes
core selling pointautomatic, high precision
Power (W)6000
noise30-34dB
Control methodremote control
Voltage380 V
Cooling methodcountercurrent
Important attributes
Voltage
380 V
Cooling method
countercurrent
Power (W)
6000
Material
Metal
core components
engine, motor, pump
Mechanical test report
Available
Warranty
1 year
Factory video inspection
Available
Control method
remote control
noise
30-34dB
core selling point
automatic, high precision
Origin
Shandong, China
Weight (KG)
500
brand name
One-stop
Dimensions (length*width*height)
2850*1500*2800
Product name
evaporative condenser
temperature control
-40℃ to 0℃
water flow
60 cubic meters/hour
shape
square
Application
Industrial cooling system
Material
Stainless steel 304
size
2850*1500*2800/customized
Elliptical tube wall thickness
1.2mm or 1.5mm
Freezer type
Liquid nitrogen evaporation freezing
color
silver
Packaging and shipping
sales unit
single item
Individual package size
300X200X300 cm
Gross weight of a single product
500.0 kg
